Home/Equipment/Subwoofers/JL Audio/12W3v3-4 - Subwoofer Driver - 500 Watt - 12"

JL Audio 12W3v3-4 Subwoofer - 500W RMS, 12-inch, 4-Ohm SVC - Black rubber surround, polypropylene cone, large magnet, push terminals

12W3v3-4 - Subwoofer Driver - 500 Watt - 12"

Name: 12W3v3-4 - Subwoofer Driver - 500 Watt - 12"
Brand: JL Audio
Price: 409.99 USD
Availability: OutOfStock

The JL Audio W3v3 is a medium-power subwoofer line designed to deliver crisp, articulate bass performance in small-enclosure applications. Features DMA-optimized motor system ensuring precise, linear cone movement and polypropylene cone construction for durability and sound clarity. Elevated frame cooling technology aids heat dissipation. Supports both sealed and ported enclosure applications.

Used in 0 builds

View All JL Audio Subwoofers

Thiele-Small Parameters

Measured at small signal levels per AES standards

Electromechanical

F_s(Resonant frequency)

28 Hz

R_e(DC resistance)

4 Ω

L_e(Inductance)

1 mH

BL(Force factor)

15 T·m

Q Factors

Q_ts(Total Q)

0.4

Q_es(Electrical Q)

0.35

Q_ms(Mechanical Q)

5.5

Compliance & Mass

V_as(Equiv. volume)

60 L

M_ms(Moving mass)

200 g

C_ms(Compliance)

0.1 mm/N

S_d(Piston area)

500 cm²

Excursion

X_max(Linear excursion)

12 mm

Sensitivity

SPL₀(1W/1m)

85 dB

Power Handling

P_e(RMS power)

500 W

Parameters measured per AES2-1984 (r2003) standards. Small-signal parameters valid within linear operating region.
